10000L 3 Layers Blow Molding Machine Water Tank Making Machinery
10000L 3 Layers Blow Molding Machine Water Tank Making Machinery
| plastic processed | HDPE, PE, HDPE/PP | Clamping Force (kN) | 6000 |
| voltage | 380V | automation | Automatic |
| No. of Screw Heating Zone | 6 | plc brand | Siemens |
| core components | PLC, Bearing, Gearbox, Motor, Pump | key selling points | Energy Saving |
| machinery test report | Provided | video outgoing-inspection | Provided |
| output (kg/h) | 950 kg/h | power (kw) | 1080 |
| weight (t) | 280 | dimension(l*w*h) | 18*14*10M |
| Screw L/D Ratio | 35 | screw diameter (mm) | 125 mm |
| screw heating power(kw) | 100 kW | extruder motor power(kw) | 132 kW |
| mold platen size(width)(mm) | 3000 mm | mold platen size(height)(mm) | 3600 mm |
| air pressure(mpa) | 0.8 MPa | air comsumption(m³/min) | 8 m³/min |
| die head heating power(kw) | 178 kW | After-sales Service Provided | Engineers available to service machinery overseas |
| AUTOMATIC | TOUCH SCREEN | Plastic Processed | PE, HMHDPE HDPE |
| High Efficiency | Fast Delivery | High Configuration | Siemens |
| Weight | 190TON | Blow Moulding Type | Extrusion Blow Moulding |
| Advantages | Simple Operation | Key words | Automatic Extrusion Blow Moulding Machine |
