150 Ton High Efficiency Mini Household Making Plastic Injection Machine With Center Locking Mechanism
150 Ton High Efficiency Mini Household Making Plastic Injection Machine With Center Locking Mechanism
| machine type | Hybrid, Hydraulic, Electric | style | Horizontal |
| key selling points | Energy Saving | ejector number | 13 |
| core components | Motor, Pump, PLC, Pressure Vessel | machinery test report | Provided |
| video outgoing-inspection | Provided | plasticizing capacity(g/s) | 51.9 |
| injection weight (g) | 1226 g | injection rate (g/s) | 337 g/s |
| weight (kg) | 12500 kg | power (kw) | 60 kW |
| mold height(mm) | 250 - 700 mm | ejector stroke(mm) | 170 mm |
| ejector force(kn) | 95 kN | theoretical shot volume(cm³) | 1347 cm³ |
| screw speed (rpm) | 1 - 183 rpm | screw diameter (mm) | 70 mm |
| Screw L/D Ratio | 20 | open stroke(mm) | 660 mm |
| Product name | 150 Ton High Efficiency Mini Household Making Plastic Injection Machin |
