Automatic Plastic Injection Molding Machine Vertical Injection Molding Machine
Automatic Plastic Injection Molding Machine Vertical Injection Molding Machine
| machine type | Hydraulic | distance between tie bars | 720*690mm |
| style | VERTICAL | key selling points | High-Accuracy |
| core components | Motor, PLC, Engine | machinery test report | Provided |
| video outgoing-inspection | Provided | injection weight (g) | 772 g |
| injection rate (g/s) | 238 g/s | weight (kg) | 189000 kg |
| power (kw) | 110 kW | ejector stroke(mm) | 730 mm |
| ejector force(kn) | 6.7 kN | theoretical shot volume(cm³) | 919 cm³ |
| screw speed (rpm) | 141 - 179 rpm | screw diameter (mm) | 60 mm |
| Screw L/D Ratio | 21 | open stroke(mm) | 730 mm |
| Product name | injection molding machine | Model | OR-IM260 |
| Screw diameter | 60mm | Theoretical shot volume | 848cm³ |
| Shot weight (PS) | 772g | Length/Diameter ratio | 21L/D |
| Injection stroke | 300mm | Max. screw speed | 141rpm |
| Plasticizing capacity | 38.3g/s | Injection unit force | 9.1Ton |
