Four Roll Rubber Calender for Rubber Coating and Sheet Forming Production Line
Four Roll Rubber Calender for Rubber Coating and Sheet Forming Production Line
| Roll Diameter (mm) | 360, 450, 610, 1120 | Max. Nip Load (kN) | 3000 kN |
| Power (kW) | 55 | voltage | 380 V |
| machinery test report | Provided | video outgoing-inspection | Provided |
| core components | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump | key selling points | Automatic, Multifunctional, High-Accuracy, Competitive Price, Energy Saving, Eco-Friendly, High Safety Level |
| weight (kg) | 13000 | dimension(l*w*h) | 3300*940*2350 |
| Model | XY-4F360*1120 | Roller Diameter x Length (mm) | 360x1120 |
| Linear Velocity | 0.73:1 1:0.73 | Middle roller Friction Ratio(r/min) | 2-20.1 |
| INip Adjust Range(mm) | 0-10 | Production Min Thickness(mm) | 0.2 |
| Products Width | 500-920 | Motor Power(kw) | 55 |
| Dimension Size(mm) | 3300x940x2350 | Weight(t) | 13 |
