Lab Mini Plastic Injection Molding Machine
Lab Mini Plastic Injection Molding Machine
| machine type | Electric | plastic processed | PP, PET, PVC, PPR, EVA, PE |
| style | VERTICAL | key selling points | High-Accuracy |
| ejector number | Other | core components | Bearing, Motor, Pump |
| machinery test report | Provided | video outgoing-inspection | Provided |
| plasticizing capacity(g/s) | 25.4 | injection weight (g) | 45 |
| injection rate (g/s) | 10 | weight (kg) | 380 |
| power (kw) | 2.2 | mold height(mm) | 1 - 85 mm |
| ejector stroke(mm) | 82 | ejector force(kn) | 26 |
| theoretical shot volume(cm³) | 10 | screw diameter (mm) | 25 |
| open stroke(mm) | 82 | Feeding torque | 25.4NM |
| Pressure | 0.8Mpa | Injection stroke | 0-85mm |
| Feeding speed | 1-130rpm | Mold opening stroke | 82mm |
| Injection force | 1800kg | Injection capacity | 45g |
| Maximum temperature | Zone 1/2 360℃; Zone3 180℃ | Control accuracy | 0.5℃ |
| Screw diameter | 25mm |
