Mini Desktop Vertical Injection Molding Machine Compact High Precision for Plastic Parts Small Injection Molding Equipment
Mini Desktop Vertical Injection Molding Machine Compact High Precision for Plastic Parts Small Injection Molding Equipment
| machine type | Hydraulic | distance between tie bars | 355*355 |
| plastic processed | PP, PC, ABS, PET, LDPE, PE/PP | style | VERTICAL |
| key selling points | High-Accuracy | ejector number | Other |
| core components | Motor, Pump, PLC, Pressure Vessel | machinery test report | Provided |
| video outgoing-inspection | Provided | plasticizing capacity(g/s) | 9.9 |
| injection weight (g) | 110 | injection rate (g/s) | 98 |
| weight (kg) | 3300 | power (kw) | 6.2 |
| mold height(mm) | 150 - 380 mm | ejector stroke(mm) | 100 |
| ejector force(kn) | 32 | theoretical shot volume(cm³) | 120 |
| screw speed (rpm) | 1 - 230 rpm | screw diameter (mm) | 42 |
| Screw L/D Ratio | 21 | open stroke(mm) | 310 |
| color | white |
