Plastic Stretch Film Extrusion Cast Thin Soft Transparent Film Extruder Manufacturing Film Machine Production Line
Plastic Stretch Film Extrusion Cast Thin Soft Transparent Film Extruder Manufacturing Film Machine Production Line
| application | Bar, Wire, Pipe, Sheet, Film, Profile, Plates, Filament, Pelletizing, building | plastic processed | PE, PP, PVC, PC, PE/PP |
| extruder type | single screw | screw diameter (mm) | 50 |
| voltage | 75KW | Screw L/D Ratio | 34:1 |
| Screw Material | 38CrMoALA | key selling points | High Productivity |
| machinery test report | Provided | video outgoing-inspection | Provided |
| core components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw | Screw Design | Single-screw |
| Screw Speed (rpm) | 100 | Weight (KG) | 20000 |
| dimension(l*w*h) | 20000*3000*3000mm | power (kw) | 110 |
| Keywords | Plastic thin film Stretch Film machine extrusion production line | Product name | Plastic PVC Stretch Film extrusion Making Machine line |
| After-sales Service Provided | Engineers available to service machinery overseas | Automatic Grade | Automatic |
| After Warranty Service | Field maintenance and repair service | Output (kg/h) | 240kg/h |
| Certification | CE Certificate | Power of main motor | 75KW-110KW |
| width of product | 1300mm | Max.dia of winding | 600mm |
