Standard Vertical Injection Molding Machine

Standard Vertical Injection Molding Machine
  • Standard Vertical Injection Molding Machine

    • Standard Vertical Injection Molding Machine

    Request a Quote
    machine typeElectricdistance between tie bars280*280mm
    plastic processedPolylactic AcidstyleHorizontal
    key selling pointsEnergy Savingcore componentsBearing, Motor, PLC, Screw
    machinery test reportProvidedvideo outgoing-inspectionProvided
    injection weight (g)15 ginjection rate (g/s)15 g/s
    weight (kg)400 kgpower (kw)10 kW
    ejector stroke(mm)100 mmejector force(kn)1800 kN
    theoretical shot volume(cm³)30 cm³screw diameter (mm)25 mm
    open stroke(mm)100 mmControl modePLC
    Table size1200*380mmPlaten size320*320mm
    Injection stroke100mmOpen stroke110~300mm
    Hang mold specification220*200mmClamp forceAbout 1800kg
    Injection quantity15gTemperature control precisionprecision: ±0.5℃
    Injection Rate30cm3/s
